TPS563200DDCRInternet thinking Electronics Co., Electronic data resources trading network.(ｖ＾＿＾)ｖ

TPS563200DDCR Datasheet, PDF

Manufacturer

Electronic Manufacturer	Part no	Datasheet	Electronics Description
Texas Instruments	TPS563200DDCR		4.5-V To 17-V Input, 2-A, 3-A Synchronous Step-Down Voltage Regulator In 6 Pin SOT-23

Product Overview

Digi-Key Part Number	296-43663-1-ND
Quantity Available
Manufacturer	Texas Instruments
Manufacturer Part Number	TPS563200DDCR
Description	IC REG BUCK ADJ 3A SYNC 6SOT
Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	23 Weeks
Detailed Description	Buck Switching Regulator IC Positive Adjustable 0.76V 1 Output 3A SOT-23-6 Thin, TSOT-23-6

Documents & Media

Datasheets	TPS562200,TPS563200 Datasheet
Design Resources	TPS563200 Design with WEBENCH® Power Designer
Featured Product	TPS563200 Synchronous Step-Down Regulator Power Management
Manufacturer Product Page	TPS563200DDCR Specifications
Online Catalog	Buck (Step-Down) IC

Product Attributes	Select All
Categories	Integrated Circuits (ICs)
Categories	PMIC - Voltage Regulators - DC DC Switching Regulators
Manufacturer	Texas Instruments
Series	D-CAP2™, Eco-Mode™
Packaging	Cut Tape (CT)
Part Status	Active
Function	Step-Down
Output Configuration	Positive
Topology	Buck
Output Type	Adjustable
Number of Outputs	1
Voltage - Input (Min)	4.5V
Voltage - Input (Max)	17V
Voltage - Output (Min/Fixed)	0.76V
Voltage - Output (Max)	7V
Current - Output	3A
Frequency - Switching	650kHz
Synchronous Rectifier	Yes
Operating Temperature	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	SOT-23-6 Thin, TSOT-23-6
Supplier Device Package	TSOT-23-6

Part no.	TPS563200DDCR
Packge/Case	SOT23-6
Manutacturer	TI
Description	穩壓器 4.5-V To 17-V Input, 2-A, 3-A Synchronous Step-Down Voltage Regulator In 6 Pin SOT-23
Datasheet	Check Datasheet
